KING Side Cord Operation

Side cord operation is suitable for low clearance applications. The system is lower and narrower than top cord systems.

Side cord operation is a basic system, easy to install and economical.

Please note:

• Only for straight, single track applications up to 12 m (40').

• A curtain center overlap up to 50 cm (20") is possible by using overlap arms.

22 Products

  1. KING Track straight

    • I-shaped curtain track profile with a weight of 3.000 g/m welded from rectangular steel tubes for professional stage applications and touring

    • The tube pitch in upper and lower cord serves for mounting of suspensions and accessories

    from£127.61 / pc.
    £153.13incl. 20% VAT

  2. KING Track Splice Set


    1. black
    £17.35 / pc.
    £20.82incl. 20% VAT

  3. KING End Stop

    black
    1. black
    £19.12 / pc.
    £22.94incl. 20% VAT

  4. Eye Bolt M10

    silver
    1. silver
    £3.36 / pc.
    £4.03incl. 20% VAT

  5. KING G-CLAMP 48/60

    • Universal Smart-Clamp for pipes with 48-60 mm diameter with anchor point for safety rope

    • Including fasteners and slot nut for direct track mounting

    • Fluted contact surface for ideal purchase

    • Multilevel receiver for fasteners M10 and M12 (wrench size 17 & 19 mm)

    • Captive clamp screw

    • Premium powder coating RAL 9005 dull black

    • TÜV certified

    1. black
    £30.97 / pc.
    £37.16incl. 20% VAT

  6. KING Wall Mount Bracket

    • For direct rail mounting or with rail suspension

    • Variable wall distance

    • Incl. fastening elements

    from£51.06 / pc.
    £61.27incl. 20% VAT

  7. KING 2-Wheel Runner

    black
    1. black
    £27.35 / pc.
    £32.82incl. 20% VAT

  8. KING 2-Wheel Runner 2+2

    black
    1. black
    £36.46 / pc.
    £43.75incl. 20% VAT

  9. KING Master Runner 4+4

    • 4 load bearing and 4 bottom stabilizing wheels, ball bearing

    • With side cord attachment

    1. black
    £182.30 / pc.
    £218.76incl. 20% VAT

  10. KING Master Runner 4+4 with Limit Switch Arm

    • 4 load bearing and 4 bottom stabilizing wheels, ball bearing

    • With side cord attachment

    1. black
    £246.11 / pc.
    £295.33incl. 20% VAT

  11. KING Overlap Arm

    black
    1. black
    £41.06 / pc.
    £49.27incl. 20% VAT

  12. KING HD Master Runner 60 with Rope Attachment

    • Heavy-duty runner 60 with rope attachment

    • 4 load-bearing/support rollers and guide rollers each, ball-bearing mounted

    • with mounting hole Ø 12 mm.

    • Not compatible with cover bracket

    1. black
    £360.09 / pc.
    £432.11incl. 20% VAT

  13. KING Carrier,rope attachm,limit sw.arm,side cord application

    • Heavy-duty carrier 60 with cable attachment

    • With limit switch bracket for lateral cable guide

    • 4 carrying/support and guide rollers each, ball bearing mounted

    • with mounting hole Ø 12 mm.

    1. black
    £418.59 / pc.
    £502.31incl. 20% VAT

  14. KING Scenery Carrier complete

    • 4 load bearing and 4 bottom stabilizing wheels, plastic, ball bearing

    • For side cord operation

    • For scenery, thickness 8-90 mm

    1. black
    £259.82 / pc.
    £311.78incl. 20% VAT

  15. KING Scenery Carrier complete with Limit Switch Arm

    • 4 load bearing and 4 bottom stabilizing wheels, plastic, ball bearing

    • For side cord operation

    • For scenery, thickness 8-90 mm

    1. black
    £314.51 / pc.
    £377.41incl. 20% VAT

  16. KING Return Pulley

    black
    1. black
    £76.55 / pc.
    £91.86incl. 20% VAT

  17. KING Head Pulley

    • Diverts operating and returning rope to the floor

    • Ball bearing, fastening bolt included. For rope up to Ø 8 mm

    1. black
    £154.96 / pc.
    £185.95incl. 20% VAT

  18. KING Head Pulley for HD Master Runner

    • Diverts operating and returning rope to the floor

    • Ball bearing, fastening bolt included. For rope up to Ø 8 mm

    1. black
    £205.13 / pc.
    £246.16incl. 20% VAT

  19. KING Side Cord Guide

    black
    1. black
    £61.95 / pc.
    £74.34incl. 20% VAT

  20. KING HD Side Cord Guide

    black
    1. black
    £77.52 / pc.
    £93.02incl. 20% VAT

  21. KING Center Crossover Cord Guide

    black
    1. black
    £159.56 / pc.
    £191.47incl. 20% VAT

  22. Polyester Pull Rope

    • 100 % polyester
    • black
    • Ø 8,00 mm, tensile strength approx. 1.150 daN.
    1. black
    £2.48 / rm
    £2.98incl. 20% VAT
