Manual Operation - Double Top Cord Operation
Products
TRUMPF 95 Track straight
TRUMPF 95 Track curved - with Splice
End Stop
End Stop HD
Track Suspension Bracket for Double Top Cord Applications
G-CLAMP 48/60 incl. fasteners for suspension mounting
Wall Mount Bracket
G3-Silence 2-Wheel Runner
Master Runner with Overlap Arm
Return Pulley
Head Pulley
Double Top Cord Guide
Double Top Cord Guide
Adjustable Floor Pulley
HAND-DRIVE
Stirrup Floor Pulley with foot stirrup
Floor Pulley for Weighting Sandback
Polyester Rope
TRUMPF 95 Track straight
• Extruded Aluminium profile EN-AW- 6060 T66
• Groove on top of track for mounting accessories
- black
- silver anodized
from€32.00 / rm
€38.08 incl. 19% VAT
TRUMPF 95 Track curved - with Splice
• Extruded Aluminium profile EN-AW- 6060 T66
• Groove on top of track for mounting accessories
• 1/4 circle, 90° curve
• Radius min. 50 cm
- black
- silver anodized
from€175.10 / pc.
€208.37 incl. 19% VAT
TRUMPF 95 Track Splice
• Connects two track sections
• Joint pint included
€28.00 / pc.
€33.32 incl. 19% VAT
TRUMPF 95 End Stop
• With hole to attach the curtain
€18.50 / pc.
€22.02 incl. 19% VAT
TRUMPF 95/STUDIO End Stop HD
• With set screws
- black
- silver
€20.60 / pc.
€24.51 incl. 19% VAT
TRUMPF 95 Slot Nut
• For accessories mounting
• Can be positioned at any place in the top groove of the track
• With hole to accept M8 bolt
€2.40 / pc.
€2.86 incl. 19% VAT
TRUMPF 95 Slot Nut
• Positioned in top groove of the track
• With hole to accept M8 bolt
€9.00 / pc.
€10.71 incl. 19% VAT
TRUMPF 95 Track Suspension Bracket for Double Top Cord Applications
• Camlock nut included
• With hole to accept M12 bolt
• For structure mounting or G-CLAMP Art.-No. 3100008091 mounting
€42.20 / pc.
€50.22 incl. 19% VAT
TRUMPF 95 Double Track Suspension Bracket
• Universal and central suspension for (single and) double track systems
• As offset suspension bracket if oriented with the track and as centre overlap or double track system suspension bracket if turned 90° crosswise to the track
• Centre mark for easy positioning with or crosswise to the track run
• With through hole M12 for mounting to substructure or G-CLAMP 50/60 Art.-N°: 4302009061
€29.90 / pc.
€35.58 incl. 19% VAT
G-CLAMP 48/60 incl. fasteners for suspension mounting
• Universal Smart-Clamp 48-60 mm diameter with anchor point for safety rope
• Including fasteners for suspension mounting
• Fluted contact surface for ideal purchase
• Multilevel receiver for fasteners M10 and M12 (wrench size 17 & 19 mm)
• Captive clamp screw
• Premium powder coating RAL 9005 dull black
• TÜV certified
€33.00 / pc.
€39.27 incl. 19% VAT
Wall Mount Bracket
• For suspension bracket mounting
• Variable wall distance
• Including fasteners for suspension bracket mounting
- black
- silver
from€56.00 / pc.
€66.64 incl. 19% VAT
STUDIO/TRUMPF G3-Silence 2-Wheel Runner
• Polymer body with rubber bumps to reduce stowage noise
• Ball raced wheel with high-performance plastics tire for minimized noise emission
• Curtain mounting on 360°-plastics-swivel plus lateral receivers for curtain hooks
• Required every 20 cm as standard
- white
- black
€13.00 / pc.
€15.47 incl. 19% VAT
TRUMPF 95 Master Runner
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• With rope attachment
€175.10 / pc.
€208.37 incl. 19% VAT
TRUMPF 95 Master Runner with Overlap Arm
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• With rope attachment
• Load capacity not applicable with overlap arms
€216.30 / pc.
€257.40 incl. 19% VAT
TRUMPF 95 Scenery Runner with Scenery Attachment
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• Load pick up with cardanic bedded fastening M8
• Technical details: please see Art.-No. 3100000071
• For scenery, thickness: 8-60 mm
€252.40 / pc.
€300.36 incl. 19% VAT
TRUMPF 95 Return Pulley
• Returns rope 180º at end of track
• Ball bearing
• Camlock nut included
• For rope up to Ø 8 mm
€82.40 / pc.
€98.06 incl. 19% VAT
TRUMPF 95 Head Pulley
• Diverts operating and returning rope to the floor
• Ball bearing
• Camlock nut included
• For rope up to Ø 8 mm
€144.20 / pc.
€171.60 incl. 19% VAT
TRUMPF 95 Horizontal Deviation Pulley
• Diverts operationg rope horizontally
• Ball bearing
• Camlock nut included
• For rope up to Ø 8 mm
€123.60 / pc.
€147.08 incl. 19% VAT
TRUMPF 95 Double Top Cord Guide
• For straight track sections
• Guides operating and returning cord
• Camlock nut included
• For rope up to Ø 8 mm
€43.30 / pc.
€51.53 incl. 19% VAT
TRUMPF 95 Double Top Cord Guide
• For curved track sections
• Guides operating and returning cord
• Camlock nut included
• For rope up to Ø 8 mm
€88.60 / pc.
€105.43 incl. 19% VAT
Adjustable Floor Pulley
• With Ø 10 mm hole for screwing on the floor
• Tensioning by adjustable pulley
• For rope up to Ø 8 mm
from€93.70 / pc.
€111.50 incl. 19% VAT
HAND-DRIVE
• Cord-Drive with integrated cord tensioner and a guided pair of spings
• Removable cover for commissioning and maintenance
• Centre mark for easy positioning perpendicularly to the track run
• Slot holes for easy mounting and adjustment
• Star knob allows toolless change of the crank lever in two positions: Short lever = fast; Long lever = strong
• The crank lever is equipped with a foldaway handle and may be locked in both positions (padlock is not in scope of delivery)
• Sticker "open/close" for individual signage of turning direction (provided detached)
• Curtain Speed and Drag Force at 60 rpm on the winch and Hand force 200 N
€675.00 / pc.
€803.25 incl. 19% VAT
Stirrup Floor Pulley with foot stirrup
• With foot stirrup and Ø 10 mm hole for screwing on the floor
• Tensioned by foot pressure
• For rope up to Ø 8 mm
€97.90 / pc.
€116.50 incl. 19% VAT
Floor Pulley for Weighting Sandback
• With receiving hole Ø 8,5 mm
• Rope tension with the aid of the sandsack (not included in scope of delivery)
• For rope up to Ø 8 mm
• Including quick link DIN 56927-B NG6
€84.50 / pc.
€100.56 incl. 19% VAT
Self Tensioning Floor Pulley
• With Ø 10 mm hole for screwing on the floor
• Tensioning via metal block
• For mobile applications
• For rope up to Ø 8 mm
€185.40 / pc.
€220.63 incl. 19% VAT
Polyester Rope
black and white,
max. ropelength: 200,00 rm,
Ø 6,00 or 8,00 mm
- white
- black
from€1.60 / rm
€1.90 incl. 19% VAT
KEVLAR rope
black, Ø 8,00 mm,
hardly stretchable (approx. 1 %), tensile strength approx. 1.200 daN.
€4.80 / rm
€5.71 incl. 19% VAT
