TRAC-DRIVE Cord Drives - One Piece Single Track
Produtos
TRUMPF 95 Track straight
TRUMPF 95 Track curved - with Splice
Track Splice
Connection Pins Touring, Set of 10
Joint Pins, Set of 10
TRUMPF 95/STUDIO End Stop HD
Top Cord Track Suspension Bracket
G-CLAMP 48/60 incl. fasteners for suspension mounting M12
Wall Mount Bracket
STUDIO/TRUMPF G3-Silence 2-Wheel Runner
Master Runner with Limit Switch Arm
Return Pulley
Head Pulley Block (downwards)
Top Cord Guide
Top Cord Guide for curved track sections
Polyester Pull Rope
TRAC-DRIVE TD12
TRAC-DRIVE Mounting Bracket
Limit Switch Plate with Pulley
Limit Switch Rope Guide
G-FRAME 28 Control Cabinet
Control and Power Cable for fixed Speed
TRAC-DRIVE Secondary Remote Control Panel
Optional Accessories for Control Unit: DMX card
Hand-Held Remote Control + Receiver
TRUMPF 95 Track straight
• Extruded Aluminium profile EN-AW- 6060 T66
• Groove on top of track for mounting accessories
de€ 32,00 / m€ 38,08incl. 19% IVA
TRUMPF 95 Track curved - with Splice
• Extruded Aluminium profile EN-AW- 6060 T66
• Groove on top of track for mounting accessories
• 1/4 circle, 90° curve
• Radius min. 50 cm
de€ 175,10 / pçs€ 208,37incl. 19% IVA
TRUMPF 95 Track Splice
• Connects two track sections
• Joint pint included
- preto
€ 28,00 / pçs€ 33,32incl. 19% IVA
TRUMPF/TRUMPF 95 Connection Pins Touring, Set of 10
• Conical on one side for quick and easy assembly and disassembly of mobile track systems
• Set consisting of 10 pins Ø 2,5 mm
- prateado
€ 23,70 / pçs€ 28,20incl. 19% IVA
TRUMPF/TRUMPF 95 Joint Pins, Set of 10
• For connecting permanently installed track systems
• Also suitable for G-TRACK
- preto
€ 2,50 / pçs€ 2,98incl. 19% IVA
TRUMPF 95 End Stop
• With hole to attach the curtain
- preto
€ 18,50 / pçs€ 22,02incl. 19% IVA
TRUMPF 95/STUDIO End Stop HD
• With set screws
€ 20,60 / pçs€ 24,51incl. 19% IVA
TRUMPF 95 Slot Nut
• For accessories mounting
• Can be positioned at any place in the top groove of the track
• With hole to accept M8 bolt
- prateado
€ 2,40 / pçs€ 2,86incl. 19% IVA
TRUMPF 95 Slot Nut
• Positioned in top groove of the track
• With hole to accept M8 bolt
- preto
€ 9,00 / pçs€ 10,71incl. 19% IVA
TRUMPF 95 Top Cord Track Suspension Bracket
• Camlock nut included
• With hole to accept M12 bolt
• For structure mounting or G-CLAMP Art.-No. 3100008091 mounting
• Number and spacing depend on the load on the rail (see load diagrams in the Trumpf95 brochure)
- preto
€ 29,90 / pçs€ 35,58incl. 19% IVA
G-CLAMP 48/60 incl. fasteners for suspension mounting M12
• Universal Smart-Clamp 48-60 mm diameter with anchor point for safety rope
• Including fasteners for suspension mounting
• Fluted contact surface for ideal purchase
• Multilevel receiver for fasteners M10 and M12 (wrench size 17 & 19 mm)
• Captive clamp screw
• Premium powder coating RAL 9005 dull black
• TÜV certified
- preto
€ 33,00 / pçs€ 39,27incl. 19% IVA
Wall Mount Bracket
• For suspension bracket mounting
• Variable wall distance
• Including fasteners for suspension bracket mounting
de€ 56,00 / pçs€ 66,64incl. 19% IVA
STUDIO/TRUMPF G3-Silence 2-Wheel Runner
• Polymer body with rubber bumps to reduce stowage noise
• Ball raced wheel with high-performance plastics tire for minimized noise emission
• Curtain mounting on 360°-plastics-swivel plus lateral receivers for curtain hooks
• Required every 20 cm as standard
€ 13,00 / pçs€ 15,47incl. 19% IVA
TRUMPF 95 Master Runner
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• With rope attachment
- preto
€ 164,80 / pçs€ 196,11incl. 19% IVA
TRUMPF 95 Master Runner with Overlap Arm
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• With rope attachment
- preto
€ 206,00 / pçs€ 245,14incl. 19% IVA
TRUMPF 95 Master Runner with Limit Switch Arm
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• With rope attachment
- preto
€ 221,50 / pçs€ 263,59incl. 19% IVA
TRUMPF 95 Scenery Runner with Scenery Attachment
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• Load pick up with cardanic bedded fastening M8
• Technical details: please see Art.-No. 3100000071
• For scenery, thickness: 8-60 mm
- preto
€ 252,40 / pçs€ 300,36incl. 19% IVA
TRUMPF 95 Scenery Runner with Scenery Attachment, Top Cord Rope Attachment and Limit Switch Arm
• 4 top load bearing and 4 bottom stabilizing wheels, ball bearing
• With fall protection
• Load pick up with cardanic bedded fastening M8
• For scenery, thickness: 8-60 mm
- preto
€ 303,90 / pçs€ 361,64incl. 19% IVA
TRUMPF 95 Return Pulley
• Returns rope 180º at the end of track
• Ball bearing
• Camlock nut included
• For rope up to Ø 8 mm
- preto
€ 89,60 / pçs€ 106,62incl. 19% IVA
TRUMPF 95 Head Pulley Block (downwards)
• Diverts operating and returning cord downwards
• Ball raced pulleys for operating cord up to Ø 8 mm and cord keepers
• Individual arrangement along the track with sliding nuts
• Incl. fasteners and slot nuts
- preto
€ 144,20 / pçs€ 171,60incl. 19% IVA
TRUMPF 95 Head Pulley Block (upwards)
• Diverts operating and returning cord downwards
• Ball raced pulleys for operating cord up to Ø 8 mm and cord keepers
• Individual arrangement along the track with sliding nuts
• Incl. fasteners and slot nuts
- preto
€ 154,50 / pçs€ 183,86incl. 19% IVA
TRUMPF 95 Horizontal Deviation Pulley
• Diverts operationg rope horizontally
• Ball bearing
• Camlock nut included
• For rope up to Ø 8 mm
- preto
€ 123,60 / pçs€ 147,08incl. 19% IVA
TRUMPF 95 Top Cord Guide
• For straight track sections
• Guides operating and returning cord
• Camlock nut included
• For rope up to Ø 8 mm
- preto
€ 24,70 / pçs€ 29,39incl. 19% IVA
TRUMPF 95 Top Cord Guide for curved track sections
• For curved track sections
• Guides operating and returning cord
• Ball bearing
• Camlock nut included
• For rope up to Ø 8 mm
- preto
€ 42,20 / pçs€ 50,22incl. 19% IVA
Polyester Pull Rope
- 100 % polyester
- black
- Ø 8,00 mm, tensile strength approx. 1.150 daN.
- preto
€ 2,80 / m€ 3,33incl. 19% IVA
TRAC-DRIVE TD12
• 2-grooved pulley, direct cabling
• 40 % duty cycle
• 3 x 230 / 400 VAC - other voltages available
€ 3.162,10 / pçs€ 3.762,90incl. 19% IVA
TRAC-DRIVE TD30
• 3 grooved pulleys, direct cabling
• 40 % duty cycle
• 3 x 230 / 400 VAC - other voltages available
€ 3.883,10 / pçs€ 4.620,89incl. 19% IVA
TRUMPF 95 TRAC-DRIVE Mounting Bracket
• For direct track mounting
• For TD12 and TD30
- preto
€ 52,50 / pçs€ 62,48incl. 19% IVA
TRAC-DRIVE Precabling of motor with 2 limit switches
• Preparation for motor connections / limit switch 2 pieces on terminal strip
• XRL connection for limit switch cable
• for drive with fixed speed
• Recommended for on-site control
€ 391,40 / pçs€ 465,77incl. 19% IVA
TRAC-DRIVE Precabling of motor for 4 limit switches
• Preparation for motor connections / limit switch 4 pieces on terminal strip
• XRL connection for limit switch cable
• for drive with fixed speed
• Recommended for on-site control
€ 448,10 / pçs€ 533,24incl. 19% IVA
TRUMPF 95 Limit Switch, Track Mounted
• With track mounting plate
• Camlock nut included
• Without cable
- preto
€ 67,00 / pçs€ 79,73incl. 19% IVA
TRUMPF 95 Limit Switch Plate with Pulley
• With track mounting plate
• Without cable
- preto
€ 91,70 / pçs€ 109,12incl. 19% IVA
TRUMPF 95 Limit Switch Rope Guide
• Directs rope around limit switch
• Ball bearing
• Camlock nut included
• For rope up to Ø 8 mm
- preto
€ 27,80 / pçs€ 33,08incl. 19% IVA
TRAC-DRIVE G-FRAME 28 Control Cabinet
• For constant speed
• Functions: Open / Stop / Close
• 3 x 230 / 400 VAC - 50 Hz - other voltages available
• For direct cabling
• Including accessories for 19" rack or wall mounting
• W x h x d: 444 x 220 x 290 mm
- preto
€ 2.788,30 / pçs€ 3.318,08incl. 19% IVA
TRAC-DRIVE G-FRAME 54 Control
• For constant speed
• Functions: Open / Stop / Close
• 3 x 230 / 400 VAC - 50 Hz - other voltages available
• For direct cabling
• Including accessories for 19" rack or wall mounting
• W x h x d: 444 x 220 x 550 mm
- preto
€ 2.953,10 / pçs€ 3.514,19incl. 19% IVA
Control and Power Cable for fixed Speed
• Connection cable between motor and control unit
de€ 185,40 / pçs€ 220,63incl. 19% IVA
TRAC-DRIVE Secondary Remote Control Panel
• For direct cabling
• W x H x D: 337 x 125 x 175 mm
• No intermediate position
de€ 957,90 / pçs€ 1.139,90incl. 19% IVA
TRAC-DRIVE Optional Accessories for Control Unit 3 intermediate positions
• Optional: maximum 3 intermediate positions (additional incremental encoder required)
€ 973,40 / pçs€ 1.158,35incl. 19% IVA
Optional Accessories for Control Unit: DMX card
• DMX card with following functions: open/close
€ 700,40 / pçs€ 833,48incl. 19% IVAOptional Accessories for Control Unit: DMX card
• DMX card with following functions: open/close and speed
€ 1.122,70 / pçs€ 1.336,01incl. 19% IVAOptional Accessories for Control Unit: DMX card
• DMX card with following functions: open/stop/close/speed
• max. 3 intermed. positions
€ 1.452,30 / pçs€ 1.728,24incl. 19% IVA
TRAC-DRIVE G-FRAME 54 Control Cabinet
• For variable speed
• Functions: Open / Stop / Close Potentiometer
• 1 x 230 VAC - 50 Hz - other voltages available, direct cabling
• W x h x d: 444 x 220 x 550 mm
- preto
€ 3.849,20 / pçs€ 4.580,55incl. 19% IVA
Control and Power Cable for Variable Speed
• Connection cable between motor and control unit
de€ 427,50 / pçs€ 508,73incl. 19% IVA
TRAC-DRIVE Additional Charge, Incremental encoder integrated
• Additional equipment Incremental encoder, mounted on motor
- preto
€ 1.246,30 / pçs€ 1.483,10incl. 19% IVA
TRUMPF 95 Return Pulley with Integral Incremental Encoder
• With integrated incremental encoder
• 500 pulses / rotation
- preto
€ 870,40 / pçs€ 1.035,78incl. 19% IVA
TRAC-DRIVE Emergency Stop Button for DMX-control
- length: 25,00 m, for TUBE, MEGASCREEN TOUR and MEGASCREEN.
- preto/amarelo
€ 252,40 / pçs€ 300,36incl. 19% IVA
Extension cable Emergency STOP DMX function 25m
- STOP DMX function
- length: 25,00 m, for TUBE,MEGASCREEN TOUR and MEGASCREEN.
- preto
€ 164,80 / pçs€ 196,11incl. 19% IVA
Hand-Held Remote Control + Receiver
• Narrow band FM modulation
• Frequency: 433-434 MHz
• PLL synthesizer
• Without speed regulation
- preto/amarelo
€ 1.122,70 / pçs€ 1.336,01incl. 19% IVA
Hand-Held Remote Control + Receiver with Emergency Stop Circuit
• Narrow band FM modulation
• Frequency: 433-434 MHz
• PLL synthesizer
• Without speed regulation
- preto/amarelo
€ 2.451,40 / pçs€ 2.917,17incl. 19% IVA
